JETSON TX1 DEVELOPER KIT
Full-featured development platform for visual computing
JETSON TX1 DEVELOPER KIT

The Jetson TX1 Developer Kit is a full-featured development platform for visual computing designed to get you up and running fast.

It comes pre-flashed with a Linux environment, includes support for many common APIs, and is supported by NVIDIA's complete development tool chain. The board also exposes a variety of standard hardware interfaces, enabling a highly flexible and extensible platform. This makes it ideal for all your applications requiring high computational performance in a low-power envelope.

For software updates and the developer SDK, visit our Jetson Developer Platform. The SDK includes an OS image that you will load onto your device, developer tools, supporting documentation, and code samples to help you get started.




Key Features

Jetson TX1 Module

  • NVIDIA Maxwell™ GPU with 256 NVIDIA® CUDA® Cores
  • Quad-core ARM® Cortex®-A57 MPCore Processor
  • 4 GB LPDDR4 Memory
  • 16 GB eMMC 5.1 Flash Storage
  • Connects to 802.11ac Wi-Fi and Bluetooth enabled devices
  • 10/100/1000BASE-T Ethernet

JETSON CAMERA MODULE

  • 5 MP Fixed Focus MIPI CSI Camera

Buttons

  • Power On/Off
  • Reset
  • Force Recovery
  • User-Defined

Power Options

  • External 19V AC adapter

I/O

  • USB 3.0 Type A
  • USB 2.0 Micro AB (supports recovery and host mode)
  • HDMI
  • M.2 Key E
  • PCI-E x4
  • Gigabit Ethernet
  • Full-Size SD
  • SATA Data and Power
  • GPIOs, I2C, I2S, SPI*
  • TTL UART with Flow Control
  • Display Expansion Header*
  • Camera Expansion Header*

* I/O expansion headers: refer to product documentation for header specification.

KIT CONTENTS

  • NVIDIA Jetson TX1 Developer Board
  • AC Adapter
  • Power Cord
  • USB Micro-B to USB A Cable
  • USB Micro-B to Female USB A Cable
  • Rubber Feet (4)
  • Quick Start Guide
  • Safety Booklet
  • Antennas to connect to Wi-Fi enabled devices (2)


The following items are recommended, but not included:

  • HDMI Display and Cable (Type A)
  • Keyboard and Mouse
  • JTAG Debugger
  • TTL to RS232 UART
