Quadro 4000

Revolutionary Quadro GPU architecture Modern applications harness the latest NVIDIA® CUDA™ parallel processing architecture of the Quadro GPU to deliver performance gains up to 8x faster than previous generations when running computationally intensive elements such as ray tracing, video processing and computational fluid dynamics. For mission critical applications, Quadro 4000 features fast 64-bit double precision floating point capabilities to ensure the accuracy of your results. From medical imaging to structural analysis applications, precision is assured without sacrificing performance.

Powering visual supercomputing platform Quadro 4000 is not only a graphics processor; it drives an entire visual supercomputing platform, incorporating hardware and software that enables advanced capabilities such as stereoscopic 3D, scalable visualization and 3D high-definition broadcasting.

Supercharged professional applications NVIDIA professional software technologies, from CUDA software to application acceleration engines, combined with Quadro, accelerate applications from companies such as Adobe, Autodesk, RTT, Dassault Systemes, Bunkspeed and many more.

¹ Raw throughput number calculated by graphics processing clusters, GPU clock rate, and triangle throughput.

• GPU Features
• Next-Generation NVIDIA^® CUDA™ Architecture
  Breakthrough NVIDIA CUDA parallel computing architecture, code named Fermi, tightly integrates advanced visualization and compute features delivering performance that greatly accelerates professional workflows.
• NVIDIA^® Scalable Geometry Engine™
  Dramatically improves geometry performance across a broad range of CAD, DCC and medical applications, enabling you to work interactively with models and scenes that are an order of magnitude more complex than ever before.
• Large Framebuffers with Ultra-Fast Bandwidth
  Large GPU memory with fast bandwidth for display of complex models and scenes, as well as computation of large datasets.
• NVIDIA^® Parallel DataCache™
  Supports a true cache hierarchy combined with on-chip shared memory. L1 and L2 caches drive exceptional throughput, accelerating features such as real-time ray tracing, physics and texture filtering.
• Fast 64-Bit Floating Point Precision
  Industry’s fastest double precision floating point performance enabling accurate results on mission-critical applications, including computer-aided-design, finite element analysis to computational fluid dynamics.
• NVIDIA GigaThread™ Engine
  Provides up to 10x faster context switching compared to previous generation architectures, concurrent kernel execution, and improved thread block scheduling.
• Dual Copy Engines
  Enables the highest rates of parallel data processing and concurrent throughput between the GPU and host, accelerating techniques such as ray tracing, color grading and physical simulation.
• Fast 3D Texture Transfer
  Fast transfer and manipulation of 3D textures resulting in more interactive visualization of large volumetric datasets.
• Hardware 3D Window Clipping
  Hardware accelerated clip regions (data transfer mechanism between a window and the frame buffer) improve overall graphics performance by increasing transfer speed between color buffer and frame buffer.
• Unified Driver Architecture (UDA)
  The NVIDIA UDA guarantees forward and backward compatibility with software drivers. Simplifies upgrading to a new solution because all Quadro products work with the same driver software.
• Image Quality
• Full-Scene Antialiasing (FSAA)
  Up to 64x FSAA dramatically reduces visual aliasing artifacts or “jaggies,” resulting in unparalleled image quality and highly realistic scenes.
• GPU Tessellation with Shader Model 5.0
  Quadro Tessellation Engines automatically generate finely detailed geometry, for cinematic quality environments and scenes, without sacrificing performance.
• 16K Texture and Render Processing
  The ability to texture from and render to 16K x 16K surfaces. Beneficial for applications that demand the highest resolution and quality image processing.
• NVIDIA High Precision High Dynamic Range (HDR) Technology
  Sets new standards for image clarity and quality through floating point capabilities in shading, filtering, texturing, and blending. Enables unprecedented rendered image quality for visual effects processing.
• Display Features
• High-Quality Display Connectors
  Attaches to ultra-high-resolution panels producing phenomenal photorealistic image quality from a range of display connectors. Directly through GPU, supports two active connectors including, dual-link DVI-I with up to 3840 x 2400 @ 24Hz, DisplayPort with up to up to 2560 x 1600 @ 60Hz, or HDMI from a cable.
• 30-Bit Color Fidelity
  30-bit color fidelity (10-bits per color) enables billions rather than millions of color variations for rich, vivid image quality with the broadest dynamic range¹.
• NVIDIA^® Quadro^® Digital Video Pipeline
  Quadro Digital Video Pipeline is the industry’s only GPU-accelerated solution for real-time acquisition, processing, and delivery of high-resolution SDI video, across traditional and now 3D video broadcast environments. Supports uncompressed 8-, 10-, 12-bit SDI via optional Quadro SDI Capture and Quadro SDI Output cards.
• NVIDIA^® 3D Vision Pro™
  3D Vision Pro includes advanced active shutter glasses delivering crystal-clear stereoscopic 3D visualization for the most immersive experience. RF technology enables a range of environments ranging from collaborative work spaces to theaters. 3D Vision Pro solution sold separately.
• OpenGL Quad Buffered Stereo Support
  OpenGL Quad Buffered Stereo offers professional applications the capability of smooth and immersive 3D Stereo experience.
• 3D Stereo Synchronization
  Enables robust control of stereo effect through a dedicated 3-pin mini-din connection between the graphics card and 3D stereo hardware. Support via optional 3-pin mini din connector.
• Software Support
• Programming the CUDA Parallel Computing Architecture
  General purpose GPU computing using standard programming languages like C/C++ and Fortran, and emerging APIs such as OpenCL and Direct Compute. This broad adoption of CUDA is accelerating techniques like ray tracing, video and image processing, and computation fluid dynamics.
• Cg Programming
  Programmable GPU leverages Cg high-level, open-standard shading language to enable the creation and integration of real-time photorealistic effects into 3D models, scenes and designs.
• Microsoft^® Windows^® 7 Support
  Take advantage of all the new and compelling features included with Windows 7, delivering unprecedented application performance, advanced visual realism, and premium reliability with superior application compatibility on mobile and desktop workstations.
• Shader Model 5.0 Programmability
  Infinite length vertex programs and dynamic flow control remove the previous limits on OpenGL and DirectX shader programs, delivering sophisticated effects never before imagined.
• NVIDIA Graphics API Extensions
  NVIDIA provides a set of extensions to standard graphics APIs for Linux and Windows, enabling applications to take maximum advantage of state-of-the-art GPU capabilities.
• NVIDIA^® Application Acceleration Engines Support
  Supercharge application performance and capabilities with highly optimized software modules, including SceniX and OptiX for advanced creative and investigative possibilities.
• NVIDIA® Multi-OS
  NVIDIA Multi OS allows a user to run multiple Windows or Linux workstation applications from a single system, with each Operating System directly assigned to a Quadro graphics solution. Only available on NVIDIA Multi-OS certified platforms.
• Industry Standard
• Compatible with Industry Standard Architectures
  Compatible with Microsoft and Linux operating systems, as well as Intel and AMD x86 32- and 64-bit microprocessor architectures.
• Ultra-Quiet Design
  Acoustics lower than 28db for an ultra-quiet desktop environment.

¹Available for the NVIDIA Quadro 4000 for Mac on Windows using Bootcamp.
