Quadro NVS

Comparison Chart





Product NVS 295 NVS 300 NVS 310 (New!) NVS 510 (New!) NVS 420 NVS 450
Bus Interface PCI Express x16
PCI Express x1
PCI Express x16
PCI Express x1
PCI Express x16 PCI Express x16 PCI Express x16
PCI Express x1
PCI Express x16
Memory Size 256MB GDDR3 512MB DDR3 512MB DDR3 2048 MB DDR3 512MB GDDR32 512MB GDDR32
Memory Interface 64-bit 64-bit 64-bit 128-bit 128-bit (64bit/gpu) 128-bit (64bit/gpu)
Memory Bandwidth 11.2 GB/s 12.6 GB/s 14 GB/s 28.5 GB/s 11.2 GB/s per gpu 11.2 GB/s per gpu
Form Factor SFF1 SFF1 SFF1 SFF1 SFF1 ATX Full Height,
1/2 length
CUDA Processor Cores 8 16 48 192 16 16
Display Connectors DisplayPort (2) DMS59 DisplayPort (2) mini DisplayPort (4) VHDCI (1) DisplayPort (4)
Max. Displays per Board 2 2 2 4 4 4
Max Digital Display Support 2560 x 1600 2560x1600
(DisplayPort)
1920x1200
(DVI-I)
2560x1600 3840x2160 2560 x 1600 2560 x 1600
Max Analog Display Support N/A 2048x1536 (VGA) 1920x1200 1920x1200 N/A N/A
OpenGL 3.3 3.3 4.1 4.3 3.3 3.3
DirectX 10.1 10.1 11 11 10.1 10.1
Shader Model 4.0 4.1 5 5 4.0 4.0
CUDA enabled Yes Yes Yes Yes Yes Yes
Power and Cooling 23W - Passive 17.5W - Passive 19.5W - Active5 35W - Active5 40W - Active6 35W - Passive
nView Enabled Yes Yes Yes Yes Yes Yes
DisplayPort Links 2 27 2 4 43 4
DVI Links 25 28 24 44 44 45
Analog Displays VGA N/A 29 29 49 N/A N/A
1 SFF= Small Form Factor (low profile card)
2 Through VHDCI to Quad DisplayPort dongle
3 Through VHDCI to Quad DVI-D (Single Link) dongle
4 Through DisplayPort to DVI-D industry standard cables
5 High reliability, variable speed fansink
6 Using DMS59 to DisplayPort Cable Adaptor
7 Using DMS59 to DVI-I Cable Adaptor
8 Using DMS59 to VGA Cable Adaptors
9 Through DisplayPort to VGA industry standard cables
