Product Info
Additional Info
  • Podcast

    Learn more about NVIDIA GeForce 8600M and 8400M.

  • Windows 7

    Get ready for Windows 7 with NVIDIA graphics processors. Learn more.

  • NVIDIA PureVideo® HD

    PureVideo® HD technology – delivers the ultimate HD movie experience on a notebook using less power for longer battery life

  • NVIDIA PowerMizer Technology – Extend Battery Life on Notebook PCs

    Advanced hardware and software technology specifically designed to extend the battery life of notebook PCs. Ensures that users enjoy cinematic quality and performance for extended periods of time.

  • The MXM Graphics Module

    Learn more about the mobile PCI Express module; the first consistent graphics interface for notebook PCs.



Technical Specifications
NVIDIA® Unified Architecture
  • Unified shader architecture
  • GigaThread™ technology
  • Full support for Microsoft® DirectX® 10
    • Geometry shaders
    • Geometry instancing
    • Streamed output
    • Shader Model 4.0
  • Full 128-bit floating point precision through the entire rendering pipeline
NVIDIA Lumenex™ Engine
  • 16x full screen anti-aliasing
  • Transparent multisampling and transparent supersampling
  • 16x angle independent anisotropic filtering
  • 128-bit floating point high dynamic-range (HDR) lighting with anti-aliasing
    • 32-bit per component floating point texture filtering and blending
  • Advanced lossless compression algorithms for color, texture, and z-data
  • Support for normal map compression
  • Z-cull
  • Early-Z
NVIDIA SLI™ Technology1
  • Patented hardware and software technology allows two GeForce-based graphics cards to run in parallel to scale performance and enhance image quality on today's top titles.
NVIDIA PureVideo™ HD Technology 2
  • Dedicated on-chip video processor
  • High-definition H.264, VC-1, MPEG2 and WMV9 decode acceleration
  • Advanced spatial-temporal de-interlacing
  • HDCP capable 3
  • Noise Reduction
  • Edge Enhancement
  • Bad Edit Correction
  • Inverse telecine (2:2 and 3:2 pull-down correction)
  • High-quality scaling
  • Video color correction
  • Microsoft® Video Mixing Renderer (VMR) support

Advanced Display Functionality
  • Dual-link DVI outputs for digital flat panel display resolutions up to 2560x1600
  • Dual integrated 400MHz RAMDACs for analog display resolutions up to and including 2048x1536 at 85Hz
  • Integrated HDTV encoder provides analog TV-output (Component/Composite/S-Video) up to 1080i/1080p resolution
  • NVIDIA nView® multi-display technology capability
  • 10-bit display processing
Built for Microsoft® Windows Vista™
  • Full DirectX 10 support (see above similar comment)
  • Dedicated graphics processor powers the new Windows Vista Aero 3D user interface
  • VMR-based video architecture
High Speed Interfaces
  • Designed for PCI Express® x16
  • Designed for high-speed GDDR3
Operating Systems
  • Built for Microsoft Windows Vista
  • Windows XP/Windows XP 64
  • Linux
API Support
  • Complete DirectX support, including Microsoft DirectX 10 Shader Model 4.0
  • Full OpenGL® support, including OpenGL 2.1
1SLI technology available only on select GeForce 8700M notebook GPUs.
2Feature requires supported video hardware and software. Features may vary by product.
3Requires other compatible components that are also HDCP capable.
