Certified Platform

Quadro Plex 7000 and 2200 D2
Single system using a single PCIE slot with included Host Interface Card

Vendor Model Tested OS Status
AMAX AMAX ServMax X1202
1U Two Node
Windows XP, 7 64-bit Check mark
ASUS P6T WS Windows XP, 7 64-bit Check mark
BXXo W8520 Windows XP, 7 64-bit Check mark
W4850 Windows XP, 7 64-bit Check mark
Colfax CX1265i-X5 1U Rackmount Server Windows 7 64 bit Check mark
CX2265i-X5 2U Rackmount Server Windows 7 64 bit Check mark
CX1000-XF4 1U Rackmount Server Windows 7 64 bit Check mark
CX1264-X4 1U Rackmount Server Windows 7 64 bit Check mark
CXT4000 Personal Supercomputer Windows 7 64 bit Check mark
Dell T5400 Windows XP, 7 64-bit Check mark
T7400 Windows XP, 7 64-bit Check mark
RHEL 4.5 64-bit Check mark
RHEL 5 64-bit Check mark
T5500 Windows XP, 7 64-bit Check mark
Windows XP, 7 64-bit Check mark
RHEL 4.5 64-bit Check mark
RHEL 5 64-bit Check mark
T7500 Windows XP, 7 64-bit Check mark
Windows XP, 7 64-bit Check mark
RHEL 4.5 64-bit Check mark
RHEL 5 64-bit Check mark
EVGA 790i Windows XP, 7 64-bit Check mark
RHEL 4.5 64-bit Check mark
Fujitsu Celsius R650 Windows XP, 7 64-bit Check mark
RHEL5 64-bit Check mark
Celsius V840 Windows XP, 7 64-bit Check mark
RHEL5 64-bit Check mark
Celsius M470 Windows XP, 7 64-bit Check mark
Celsius R570 Windows XP, 7 64-bit Check mark
Celsius R670 Windows XP, 7 64-bit Check mark
Celsius M720 Windows 7, Linux 64-bit Check mark
Celsius R920 Windows 7, Linux 64-bit Check mark
HP DL580 Windows XP, 7 64-bit Check mark
Xw6600 Windows XP, 7 64-bit Check mark
Xw8600 RHEL 4.5 64-bit Check mark
RHEL 5 64-bit Check mark
Windows XP, 7 64-bit Check mark
Xw9400 RHEL 5 64-bit Check mark
Z600 Windows XP, 7 64-bit Check mark
Linux RHEL 4.5 64-bit Check mark
Z800 Windows XP, 7 64-bit Check mark
Z820 Windows 7, Linux 64-bit Check mark
Littlebit axxiv SVELT LS01 Windows XP, 7 64-bit Check mark
axxiv QP001 Windows XP, 7 64-bit Check mark
TAROX Workstation H9270CR-QP Windows 7 64-bit Check mark
Workstation H9270CT-QP Windows 7 64-bit Check mark
Workstation M9270CP-QP Windows 7 64-bit Check mark
Workstation 8000 / 9000 Windows 7 64-bit Check mark
SGI Japan Asterism ID412 Windows 7, RHEL 6.1, SLES 11.1 64 bit Check mark
Asterism IDX412 Windows 7, RHEL 6.1, SLES 11.1 64 bit Check mark
Sun x4140 RHEL 4.7 64-bit Check mark
Supermicro X8DAi Windows XP, 7 64-bit Check mark


Dual Quadro Plex 7000 and 2200 D2 systems
With Optional Dual Host Interface Card (NVIDIA Part #930-50894-0501-000)

NOTE: This configuration supports Mosaic on up to 8 outputs using both Quadro Plex's. Remember to connect the G-Sync boards in the Quadro Plex's with a single CAT-5 Ethernet cable.

Vendor Model Tested OS Status
Colfax CX1000-XF4 1U Rackmount Server Windows 7 64 bit Check mark
CX1264-X4 1U Rackmount Server Windows 7 64 bit Check mark
CXT4000 Personal Supercomputer Windows 7 64 bit Check mark
HP Z820 Windows, Linux 64-bit Check mark
Z800 Windows XP, 7 64-bit Check mark
xw8600 Windows XP, 7 64-bit Check mark
Dell T7400 Windows XP, 7 64-bit Check mark
T7500 Windows XP, 7 64-bit Check mark
Fujitsu Celsius M720 Windows 7, Linux 64-bit Check mark
Celsius R920 Windows 7, Linux 64-bit Check mark
SGI Japan Asterism ID412 Windows 7, RHEL 6.1, SLES 11.1 64 bit Check mark
Asterism IDX412 Windows 7, RHEL 6.1, SLES 11.1 64 bit Check mark
TAROX Workstation 8000 / 9000 Windows 7 64-bit Check mark

Dual Quadro Plex 7000 and 2200 D2 systems
Dual systems using two PCIE slots with included Host Interface Card

NOTE: This is not a recommended configuration and supports Mosaic on only one of the installed Quadro Plex's.

Vendor Model Configuration Options
where appropriate)
Status
BoXX W8520 Windows XP, 7 64-bit Check mark
W4850 Windows XP, 7 64-bit Check mark
Fujitsu Celsius M470 Windows XP, 7 64-bit Check mark
Celsius R570 Windows XP, 7 64-bit Check mark
Celsius R670 Windows XP, 7 64-bit Check mark
HP Z600 Windows XP, 7 64-bit Check mark
Linux RHEL 4.5 64-bit Check mark
Z800 Windows XP, 7 64-bit Check mark
Z820 Windows 7, Linux 64-bit Check mark
xw8600 Windows XP, 7 64-bit Check mark
Dell T7400 Windows XP, 7 64-bit Check mark
T7500 Windows XP, 7 64-bit Check mark

Systems for use with Quadro Plex 2200 S4

Vendor Model Configuration Options Status Note
Dell PE1950 RHEL5 64-bit Check mark
R5400 Windows Server08 64-bit Check mark 2 GPU configuration
T7400 Windows Server08 64-bit Check mark 2 GPU configuration
HP DL160 RHEL5 64-bit Check mark
DL160 Windows Server08 64-bit Check mark
xw9400 Windows Server08 64-bit Check mark
xw8600 Windows Server08 64-bit Check mark
Sun x2200 RHEL5 64-bit Check mark 2 GPU configuration

Quadro Plex legacy systems

  Model Single NVIDIA Quadro Plex Dual NVIDIA Quadro Plex NVIDIA Quadro Plex 2100 S4
Certified Servers Model II Model IV Model II Model IV
Appro 1143H 1U server Check mark CP N/A N/A N/A
Appro 1522H 1U server Check mark CP N/A N/A N/A
Appro 3546H 3U server Check mark CP N/A N/A N/A
Colfax Model 1221 Check mark CP CP CP N/A
Dell Power Edge 1950 III N/A N/A N/A N/A Check mark - SBIOS version: 2.0.1
Dell PowerEdgeTM  SC1435 N/A N/A N/A N/A CP
Dell Power Edge 6950 N/A N/A N/A N/A CP
Dell Power Edge R900 N/A N/A N/A N/A CP
HP DL140 G3 CP Check mark N/A N/A Check mark (2) - SBIOS version: 1.14T4
HP DL160 G5 N/A N/A N/A N/A Check mark - SBIOS version: v.012
HP DL580 G5 CP Check mark N/A N/A CP
HP DL585 G3 CP Check mark N/A N/A N/A
HP DL785 N/A N/A N/A N/A Check mark
HP DL360 CP Check mark N/A N/A N/A
HP DL380 CP Check mark N/A N/A N/A
HP DL385 CP Check mark N/A N/A CP
IBM X3755 Check mark Check mark CP Check mark Check mark - SBIOS version: 1.12
IBM X3850 M2 N/A N/A N/A N/A CP
IBM X3950 N/A N/A N/A N/A CP
SUN Fire X2200 M2 Check mark Check mark CP CP Check mark (2) - SBIOS version: 0.81.01
SUN Sun Fire X2250 N/A Check mark N/A CP CP
SUN Fire X4100 M2 CP Check mark CP CP N/A
SUN Fire X4150 CP Check mark CP CP CP
SUN Fire X4200 M2 CP Check mark CP CP N/A
SUN Fire X4240 CP Check mark CP CP CP
SUN Sun Fire X4250 CP Check mark CP CP CP
SUN Fire X4440 CP Check mark CP CP N/A
SUN Fire X4450 N/A Check mark N/A N/A N/A
SUN Fire X4600 M2 Check mark Check mark CP Check mark CP
Certified Workstations
Boxx Boxx 7400 Check mark CP CP CP N/A
Colfax CX880 Check mark CP CP CP N/A
Dell Precision 670 Check mark CP N/A N/A N/A
Dell Precision 690 (750w) Check mark CP CP CP N/A
Fujitsu Celsius R640 N/A Check mark N/A N/A N/A
Fujitsu Celsius R650 N/A Check mark N/A N/A N/A
Fujitsu Celsius V830 CP CP CP CP N/A
Fujitsu Celsius V840 N/A Check mark N/A N/A N/A
The 3D Shop GraVT-2 64XT Check mark CP CP CP N/A
HP XW 8200 CP Check mark N/A N/A N/A
HP XW 9300 CP Check mark CP CP N/A
HP XW 9400 Check mark Check mark Check mark Check mark** N/A
HP XW 8400 Check mark CP N/A N/A N/A
IBM ZPro Check mark Check mark N/A N/A N/A
Polywell Poly Station 2055A Check mark CP CP CP N/A
SGI Asterism Power Check mark Check mark Check mark Check mark N/A
SGI Asterism Deskside Check mark Check mark Check mark Check mark N/A
SUN Ultra 20 M2 Check mark CP CP CP N/A
SUN Ultra 24 N/A Check mark N/A N/A N/A
SUN Ultra 40 Check mark CP CP CP N/A
SUN Ultra 40 M2 Check mark Check mark CP Check mark N/A
Velocity Micro ProMagix Plus 250 Check mark Check mark N/A N/A N/A
Verari Nemesys Check mark CP CP CP N/A
Verari E&P 7500 Check mark CP CP CP N/A
Wortman Terra WS M8000 CP CP N/A N/A N/A
Xi Xi MTower 2P64X Check mark CP CP CP N/A
Xi Xi MTower 2P64 Check mark CP CP CP N/A
Certified Motherboards
Supermicro H8DA3-2 Check mark Check mark CP Check mark N/A
Supermicro H8DA8-2 Check mark Check mark CP Check mark N/A
Supermicro H8DCE CP Check mark CP Check mark N/A
Supermicro H8DCE-HTe CP Check mark CP Check mark N/A
Supermicro H8DMT+ Check mark Check mark CP CP N/A
Supermicro H8DMU+ Check mark Check mark CP CP N/A
Supermicro H8QC8 CP Check mark CP CP N/A
Supermicro H8QM8 Check mark Check mark N/A N/A N/A
Supermicro H8SMI-2 Check mark Check mark CP Check mark N/A
Supermicro H8SMU CP Check mark CP CP N/A
Supermicro X7DA8 Check mark CP N/A N/A N/A
Supermicro X7DWT Check mark Check mark N/A N/A N/A
Supermicro X7QC3 CP Check mark N/A N/A N/A
Supermicro H8QM3-2 CP Check mark CP Check mark N/A
Supermicro H8DC8 CP Check mark CP Check mark N/A
Tyan S2895A2NRF Check mark Check mark CP CP N/A
Tyan S4985 CP CP CP CP N/A
Tyan S2891 CP CP CP CP N/A
Tyan S2915 CP CP CP CP N/A
Tyan S2927 CP CP CP CP N/A
Tyan S2925 Check mark CP Check mark CP N/A
Tyan S2866 Check mark Check mark Check mark CP N/A


The following platforms have been officially certified for NVIDIA Quadro® Plex VCSs:

For information on platform certification, please email us.

CP - Certification Pending
**64 Bit OS Only
(2) = 2 host systems required per Quadro Plex 2100 S4
