NVIDIA Quadro Plex

Available in four distinct models NVIDIA® Quadro® Plex is architected to meet your specific application requirements.

System Requirements

Models at a Glance
NVIDIA Quadro Plex 1000 – Model ll
Quadro Plex 2200 D2
  • Two NVIDIA Quadro FX 5800 GPUs
  • One NVIDIA Quadro G-sync board
  • Up to 4 channels
  • 64X SLI FSAA (max on single channel)



 NVIDIA Quadro Plex 1000 – Model S4 Quadro Plex 2200 S4
  • Remote Graphics System
  • Four NVIDIA Quadro FX 5800 GPUs
  • 1U Server Form Factor




Specifications
NVIDIA Quadro® Plex
  2200 D2 2200 S4
Form Factor Deskside or 3U Rackmount Kit 1U Server
NVIDIA Quadro GPU Quadro
FX 5800
Quadro
FX 5800
# NVIDIA Quadro GPUs 2 4
CUDA Processor Cores 480 960
Total Frame Buffer 8 GB
(4GB/GPU)
16 GB
(4 GB/GPU)
Option Quadro G-Sync N/A
Display Channels 4 dual-link DVI N/A**
DisplayPort 2
Key Features
SLI Mosaic Mode Y N/A
Shader Model 4.0 4.0
NVIDIA® CUDA™ Parallel Computing Processor Y Y
Genlock/frame lock Y N/A
Frame Synchronization Y N/A
FSAA (Max per Channel) 64x SLI FSAA 32x FSAA
Stereo Y N
Product Specifications
Host Connection PCI Express x8 or x16, Small Form Factor, Passive (10W)
2M (6.5 foot) NVIDIA Quadro Plex Interconnect Cable 0.5M or 2.0M Quadro Plex Interconnect Cable
Power 640W Max 1200W Max
110/240 VAC autosensing worldwide power supply
Acoustics 40dB Idle 45 dB, Max 72 dB
Form Factor Tower Desktop (9.49" H x 5.94" W x 20.55" D) or
3U Rack Mount (3U H x 8.5" W x 20.55" D)
1U Rack Mount (1.75"H x 17.4"W x 31.0" D)
Weight* 18.6lb ~40.0lbs

maximum # of Quadro Plex per host = 2

*standalone weight

**Readback Via PCI-Express Gen 2.0
