Tesla C1060 Computing Processor

NVIDIA^® Tesla™ C1060 Computing Processor enables the transition to energy efficient parallel computing power by bringing the performance of a small cluster to a workstation.

Available in Fall 2008 as integrated workstation product

Pre-purchase Assistance

Print page

Products / High Performance Computing Solutions / NVIDIA Tesla C1060

Overview

Specifications

Drivers & Downloads

Support

The NVIDIA^® Tesla™ C1060 transforms a workstation into a high-performance computer that outperforms a small cluster. This gives technical professionals a dedicated computing resource at their desk-side that is much faster and more energy-efficient than a shared cluster in the data center. The Tesla C1060 is based on the massively parallel, many-core Tesla processor, which is coupled with the standard CUDA C programming environment to simplify many-core programming.

Feeding the HPC Industry’s Relentless Demand for Performance.
Keeps pace with the increasing demands of the toughest computing challenges including drug research, oil and gas exploration, and computational finance.

Many-core Architecture Delivers Optimum Scaling across HPC Applications.
Tesla many-core architecture meets the computational demands of applications whose complexity has outstripped the CPU’s ability to solve them.

High Efficiency Computing Platform for Energy-conscious Organizations.
Higher performance and density computing for solving complex problems with fewer resources and power.

NVIDIA CUDA™ Technology Unlocks the Power of Tesla Many-core Computing Products.
The only C language environment that unlocks the many-core processing power of GPUs to solve the world’s most computationally-intensive challenges.


Features	Benefits
Massively-Parallel Many Core Architecture with 240 processor cores	Solve compute problems on your workstation that traditionally required a large cluster installation
4 GB High-Speed Memory	Enables larger datasets to be stored locally for each processor to maximize benefit from the 102GB/s memory transfer speeds and minimize data movement around the system.
Widely accepted, easy to learn CUDA C programming environment	Easily express application parallelism to take advantage of the GPU’s many core architecture
Scale to multiple GPUs and harness the performance of thousands of processor cores	Solve large-scale problems by scaling to thousands of cores across multiple GPUs
IEEE 754 single & double precision floating point units	Achieve the highest floating point performance from a single chip, while meeting the precision requirements of your application
Asynchronous transfer capability	Turbo charges system performance because data transfers can be executed concurrently with computation
512-bit memory interface from GPU to on-board memory	Fast GDDR3, 512-bit memory interface delivers 102 GB/sec memory bandwidth for blistering data transfer
Shared Data Memory	Groups of processor cores can collaborate using low latency memory
High Speed, PCI-Express Gen 2.0 Data Transfer	Fast and high-bandwidth communication between CPU and GPU
Tesla GPUs available in flexible form factor	Tesla workstation products and 1U systems enable deployment in a wide range of environments

Main | Features


Form Factor	10.5" x 4.376", Dual Slot
# of Tesla GPUs	1
# of Streaming Processor Cores	240
Frequency of processor cores	1.3 Ghz
Floating Point Precision	IEEE 754 single & double precision floating point
Total Dedicated Memory	4 GB
Memory speed	800 MHz
Memory Interface	512-bit GDDR3
Memory Bandwidth	102 GB/sec
Max Power Consumption	225 W peak, 160 W typical
System Interface	PCI Express x16 Generation 2
Auxiliary Power Connectors	6-pin & 8-pin (can be used with two 6-pins)
Thermal Solution	Active fan sink
Programming environment	C(CUDA)
